| Part Number | Photo | Freq.(MHz) | Insertion Loss | Package | Data sheet |
| CQTSR303M82.01 |  | 303.825 | 1.3dB | 5.0 x 5.0 | |
| CQTSR303M82.02 |  | 303.825 | 1.3dB | 3.5 x 5.0 | |
| CQTSR303M87.01 |  | 303.875 | 1.3dB | 3.5 x 5.0 | |
| CQTSR303M87.02 |  | 303.875 | 1.3dB | 5.0 x 5.0 | |
| CQTSR310M00.01 |  | 310 | 1.3dB | 3.5 x 5.0 | |
| CQTSR310M00.02 |  | 310 | 1.3dB | 5.0 x 5.0 | |
| CQTSR315M00.01 |  | 315 | 1.3dB | 3.5 x 5.0 | |
| CQTSR315M00.02 |  | 315 | 1.3dB | 5.0 x 5.0 | |
| CQTSR318M00.01 |  | 318 | 1.3dB | 3.5 x 5.0 | |
| CQTSR318M00.02 |  | 318 | 1.3dB | 5.0 x 5.0 | |
| CQTSR319M50.01 |  | 319.5 | 1.3dB | 3.5 x 5.0 | |
| CQTSR319M50.02 |  | 319.5 | 1.3dB | 5.0 x 5.0 | |
| CQTSR330M00.01 |  | 330 | 1.3dB | 3.5 x 5.0 | |
| CQTSR330M00.02 |  | 330 | 1.3dB | 5.0 x 5.0 | |
| CQTSR340M00.01 |  | 340 | 1.35dB | 3.5 x 5.0 | |
| CQTSR340M00.02 |  | 340 | 1.35dB | 5.0 x 5.0 | |
| CQTSR345M00.01 |  | 345 | 1.35dB | 3.5 x 5.0 | |
| CQTSR345M00.02 |  | 345 | 1.35dB | 5.0 x 5.0 | |
| CQTSR390M00.01 |  | 390 | 1.35dB | 3.5 x 5.0 | |
| CQTSR390M00.02 |  | 390 | 1.35dB | 5.0 x 5.0 | |
| CQTSR395M00.01 |  | 395 | 1.35dB | 3.5 x 5.0 | |
| CQTSR395M00.02 |  | 395 | 1.35dB | 5.0 x 5.0 | |
| CQTSR403M55.01 |  | 403.55 | 1.7dB | 3.0 x 3.0 | |
| CQTSR403M55.02 |  | 403.55 | 1.35dB | 5.0 x 5.0 | |
| CQTSR403M55.03 |  | 403.55 | 1.35dB | 3.5 x 5.0 | |
| CQTSR407M30.00 |  | 407.3 | 1.3dB | 3.5 x 5.0 | |
| CQTSR407M30.01 |  | 407.3 | 1.3dB | 5.0 x 5.0 | |
| CQTSR409M00.00 |  | 409 | 1.3dB | 3.5 x 5.0 | |
| CQTSR409M00.01 |  | 409 | 1.3dB | 5.0 x 5.0 | |
| CQTSR418M00.00 |  | 418 | 1.3dB | 3.5 x 5.0 | |
| CQTSR418M00.01 |  | 418 | 1.3dB | 5.0 x 5.0 | |
| CQTSR423M22.00 |  | 423.22 | 1.3dB | 3.5 x 5.0 | |
| CQTSR423M22.01 |  | 423.22 | 1.3dB | 5.0 x 5.0 | |
| CQTSR424M82.00 |  | 424.825 | 1.4dB | 3.0 x 3.0 | |
| CQTSR424M82.01 |  | 424.825 | 1.4dB | 3.5 x 5.0 | |
| CQTSR424M82.02 |  | 424.825 | 1.4dB | 5.0 x 5.0 | |
| CQTSR426M07.00 |  | 426.0725 | 1.4dB | 3.5 x 5.0 | |
| CQTSR426M07.01 |  | 426.0725 | 1.4dB | 5.0 x 5.0 | |
| CQTSR430M00.00 |  | 430 | 1.3dB | 3.5 x 5.0 | |
| CQTSR430M00.01 |  | 430 | 1.3dB | 5.0 x 5.0 | |
| CQTSR433M42.00 |  | 433.42 | 1.3dB | 3.5 x 5.0 | |
| CQTSR433M42.01 |  | 433.42 | 1.3dB | 5.0 x 5.0 | |
| CQTSR433M92.01 |  | 433.92 | 1.2dB | 3.5 x 5.0 | |
| CQTSR433M92.02 |  | 433.92 | 0.7dB | 3.0 x 3.0 | |
| CQTSR433M92.03 |  | 433.92 | 1.6dB | 3.0 x 3.0 | |
| CQTSR433M92.04 |  | 433.92 | 1.2dB | 5.0 x 5.0 | |
| CQTSR435M72.00 |  | 435.72 | 1.3dB | 3.5 x 5.0 | |
| CQTSR435M72.01 |  | 435.72 | 1.3dB | 5.0 x 5.0 | |
| CQTSR479M50.00 |  | 479.5 | 1.3dB | 3.5 x 5.0 | |
| CQTSR479M50.01 |  | 479.5 | 1.3dB | 5.0 x 5.0 | |
| CQTSR868M35.00 |  | 868.35 | 1.4dB | 3.5 x 5.0 | |
| CQTSR868M35.01 |  | 868.35 | 1.7dB | 3.5 x 5.0 |
